location：Home>Products>Atmospheric monitoring>Gas Sensors>Nitrogen Dioxide Detector

Nitrogen Dioxide Detector

Model：FT-QT3S

Brand：fengtu

Nitrogen Dioxide Detector is a device used to detect the concentration of nitrogen dioxide, which has the advantages of high sensitivity, fast response speed and good stability.

Get a Free Quote

Related products

1.Nitrogen Dioxide Detector Technical Parameters

Nitrogen Dioxide Detector is a device used to detect the concentration of nitrogen dioxide, which has the advantages of high sensitivity, fast response speed and good stability.

model	Measurement parameters	Measuring range	Accuracy	Resolution	unit	Operating temperature	Operating humidity
QT1	Carbon monoxide	0-1000PPM	±2PPM	1PPM	PPM	-20℃-+50℃	10-95%RH non-condensing
QT1S	Carbon monoxide	0-20PPM	≤±5%	0.01PPM	PPM	-20℃-+50℃	10-95%RH non-condensing
QT2	Sulfur dioxide	0-20PPM	±1PPM	0.1PPM	PPM	-20℃-+50℃	10-95%RH non-condensing
QT2S	Sulfur dioxide	0-1PPM	≤±5%	0.001ppm	PPM	-20℃-+50℃	10-95%RH non-condensing
QT3	Nitrogen dioxide	0-20PPM	±1PPM	0.1PPM	PPM	-20℃-+50℃	10-95%RH non-condensing
QT3S	Nitrogen dioxide	0-1PPM	≤±5%	0.001ppm	PPM	-20℃-+50℃	10-95%RH non-condensing
QT4	ozone	0-20PPM	±1PPM	0.1PPM	PPM	-20℃-+50℃	10-95%RH non-condensing
QT4S	ozone	0-1PPM	≤±5%	0.001ppm	PPM	-20℃-+50℃	10-95%RH non-condensing
QT5	Oxygen content	0~30%VOL	±3%FS	0.1%VOL	VOL	-20℃-+50℃	5-95%RH non-condensing
QT6	Negative oxygen ions	0～100,000/cm³	±10%	10pcs/cm³	Pieces/cm³	+10℃-+70℃	10-70%RH without condensation
QT7	Hydrogen sulfide	0-100PPM	±2PPM	1PPM	PPM	-20℃-+50℃	10-95%RH non-condensing
QT8	Methane	0-100%LEL	≤±3%	1%LEL	LEL	-20℃-+50℃	10-95%RH non-condensing
QT9	TVOC	0-100PPM	55±15 nA/ppm	1PPM	PPM	-20℃-+50℃	10-95%RH non-condensing
QT10	Ammonia	0-100PPM	±4PPM	1PPM	PPM	-20℃-+50℃	10-95%RH non-condensing
QT11	Nitric Oxide	0-250PPM	-2~10PPM	1PPM	PPM	-20℃-+50℃	10-95%RH non-condensing
QT12	formaldehyde	0-10PPM	<1PPM	0.1PPM	PPM	-20℃-+50℃	10-95%RH non-condensing
