Integrated Weather Station

1. Integrated Weather Station Product Introduction

Integrated Weather Station can automatically monitor a variety of factors around the clock, with automatic collection, intelligent analysis, remote management and so on.The BQX10Integrated Weather Station is a highly integrated, low-power, quick-to-install, high-precision automatic weather observation equipment that is easy to use for field monitoring.

The device supports wired, Bluetooth, GPRS and other transmission methods, requires no debugging and can be quickly deployed.It is suitable for the acquisition of meteorological data such as short-term emergency meteorological observations and mobile meteorological monitoring.Widely used in meteorology, agriculture and forestry, environmental protection, oceans, airports, ports, scientific expeditions, campus education and other fields

The device uses a ten-element integrated sensor that can conduct real-time observations of meteorological elements such as wind speed, wind direction, temperature, humidity, air pressure, light, optical rainfall, pm2.5, pm10, noise, etc.The sensor shell is made of imported Stainless steel material, which is more effective against In salt spray and other environments, the protection level reaches IP65 or above.

2.Product features of Integrated Weather Station

1.The ultrasonic probe is hidden in the top cover to avoid interference from rain and snow accumulation and avoid obstruction by natural wind☆

2.The principle is to emit continuous variable frequency ultrasonic signals and detect wind speed and direction by measuring the relative phase☆

3.Integrated sensor with ten elements: temperature, humidity, wind speed, wind direction, atmospheric pressure, optical rainfall, light, pm2.5, pm10, and noise☆

4.Standard three transmission methods: GPRS, Bluetooth, and 485 to USB

5.Aluminum alloy bracket, retractable

6.Shock-absorbing and protective trolley case, easy to carry

3.Technical parameters of Integrated Weather Station

1.Wind speed: measurement principle: ultrasonic, range: 0~60m/s, accuracy: 0.1m/s+0.01v, resolution: 0.1m/s;

2.Wind direction: Measurement principle: ultrasonic, range: 0~360°, accuracy: ±2°, resolution: 1°;

3.Air temperature: Measurement principle: diode junction voltage method, range: -40-80°C, accuracy: ±0.3°C (25°C), resolution: 0.01°C;

4.Air humidity: Measurement principle: capacitive type, range: 0-100%RH, accuracy: ±3%RH (20%~80%), resolution: 0.01%RH;

5.Atmospheric pressure: Measurement principle is piezoresistive, range: 300-1100hpa, accuracy: ±0.25%, resolution: 0.1hpa;

6.PM2.5: Range: 0-1000ug/m3, accuracy: ±10% (<500 micrograms), resolution: 1ug/m3;

7.PM10: Range: 0-1000ug/m3, accuracy: ±10% (<500 micrograms), resolution: 1ug/m3;

8.Noise: Measurement principle: capacitive type, range: 30-120dB, accuracy: ±1.5dB, resolution: 0.1dB;

9.Illumination: Measurement principle photoelectric effect, range: 0-157286LUX, accuracy: <±3%, resolution: 1LUX;

10.Optical rainfall: measurement principle: photoelectric type, range: 0-4mm/min, accuracy: ≤±4%, resolution: 0.01mm

11.Data storage: no less than 500,000 items;

12.Power consumption: 1.5W

13.Lithium battery: capacity 12000maH, battery life ≥50h, with power display function

14.Total weight of equipment: ≤5kg;

15.Installation time: 1 person, no more than 2 minutes to complete the installation;

16.The production enterprise has ISO quality management system, environmental management system and occupational health management system certification.

17.The production enterprise has a computer software registration certificate

18.The production enterprise is a 3A credit enterprise

4.Introduction to Integrated Weather Station PC software

1.PC stand-alone version of data receiving, storage, viewing and analysis software

2.Support serial port data reception, processing and display

3.Support json string, modbus485 and other communication methods

4.The storage time can be set by oneself, and the collection time can be set by oneself in the modbus485 collection mode.

5.Support self-service adding, deleting, and modifying protocols, names, icons, etc.of monitoring parameters

6.Support data post-processing function

7.Supports external running of javascript scripts

5.Introduction to Integrated Weather Station Android APP

1.Android stand-alone version of data receiving, storage, viewing and analysis software

2.Support Bluetooth data reception

3.After the mobile phone is asleep, the software receives and processes it in the background

4.JSON data automatically adds devices, and modbus devices support scanning QR codes to add devices.

5.Supports historical data viewing, analysis, and table export, and supports curve display and single data point viewing.

6.Support data post-processing function

7.Supports external running of javascript scripts

6.Introduction to Integrated Weather Station cloud platform

1.CS architecture software platform supports direct observation on mobile phones and PC browsers without installing additional software.

2.Support multiple accounts and multiple devices to log in

3.Support real-time data display and historical data display dashboard

4.Cloud servers and cloud data storage are stable and reliable, easy to expand, and load balanced.

5.Support SMS alarm and threshold setting

6.Support map display and view device information

7.Support data curve analysis

8.Support data export table format

9.Support data forwarding, HJ-212 protocol, TCP forwarding, http protocol, etc.

10.Support data post-processing function

11.Support external running of javascript scripts
