Home Weather Station

1. Home Weather Station product introduction

The Home Weather Station can accurately monitor wind speed, wind direction, temperature, humidity, precipitation, light, etc., and analyze local weather conditions. BQX8 Home Weather Station is a high-precision automatic weather observation equipment that is highly integrated, has low power consumption, can be quickly installed, and is easy to use for field monitoring.

The device supports wired, Bluetooth, GPRS and other transmission methods.It requires no debugging and can be quickly deployed.It is suitable for the acquisition of meteorological data such as short-term emergency meteorological observations and mobile meteorological monitoring.Widely used in meteorology, agriculture and forestry, environmental protection, oceans, airports, ports, scientific expeditions, campus education and other fields.

The device uses an eight-element integrated sensor that can conduct real-time observations of wind speed, wind direction, temperature, humidity, air pressure, pm2.5, pm10, noise and other meteorological elements.The sensor shell is made of imported Stainless steel material, which is more effective against environments such as salt spray and provides protection.The grade reaches IP65 or above.

2.Product features of Home Weather Station

1.The ultrasonic probe is hidden in the top cover to avoid interference from rain and snow accumulation and avoid obstruction by natural wind☆

2.The principle is to emit continuous variable frequency ultrasonic signals and detect wind speed and direction by measuring relative phase☆

3.Eight-element integrated sensor of wind speed, wind direction, temperature, humidity, air pressure, pm2.5, pm10 and noise☆

4.Standard three transmission methods: GPRS, Bluetooth, and 485 to USB

5.Aluminum alloy bracket, retractable

6.Shock-absorbing and protective trolley case, easy to carry

3.Home Weather Station technical parameters

1.Wind speed: measurement principle: ultrasonic, range: 0~60m/s, accuracy: 0.1m/s+0.01v, resolution: 0.1m/s;

2.Wind direction: Measurement principle: ultrasonic, range: 0~360°, accuracy: ±2°, resolution: 1°;

3.Air temperature: Measurement principle: diode junction voltage method, range: -40-80°C, accuracy: ±0.3°C (25°C), resolution: 0.01°C;

4.Air humidity: Measurement principle: capacitive, range: 0-100%RH, accuracy: ±3%RH (20%~80%), resolution: 0.01%RH

5.Atmospheric pressure: Measuring principle is piezoresistive, range: 300-1100hpa, accuracy: ±0.25%, resolution: 0.1hpa;

6.PM2.5: Range: 0-1000ug/m3, accuracy: ±10% (<500 micrograms), resolution: 1ug/m3;

7.PM10: Range: 0-1000ug/m3, accuracy: ±10% (<500 micrograms), resolution: 1ug/m3;

8.Noise: Range: 30-120dB, accuracy: ±1.5dB, resolution: 0.1dB;

9.Data storage: no less than 500,000 items;

10.Power consumption: 1.75W

11.Lithium battery: capacity 12000maH, battery life ≥50h, with power display function

12.Total weight of equipment: ≤5kg;

13.Installation time: 1 person, no more than 2 minutes to complete the installation;

14.The production enterprise has ISO quality management system, environmental management system and occupational health management system certification.

15.The production enterprise has a computer software registration certificate

16.The production enterprise is a 3A credit enterprise

4.Introduction to Home Weather Station PC software

1.PC stand-alone version of data receiving, storage, viewing and analysis software

2.Support serial port data reception, processing and display

3.Support json string, modbus485 and other communication methods

4.The storage time can be set by oneself, and the collection time can be set by oneself in the modbus485 collection mode.

5.Support self-service adding, deleting, and modifying protocols, names, icons, etc.of monitoring parameters.

6.Support data post-processing function

7.Support external running of javascript scripts

5.Introduction to Home Weather Station Android APP

1.Android stand-alone version of data receiving, storage, viewing and analysis software

2.Support Bluetooth data reception

3.After the mobile phone is asleep, the software receives and processes it in the background

4.JSON data automatically adds devices, and modbus devices support scanning QR codes to add devices.

5.Supports historical data viewing, analysis, and table export, and supports curve display and single data point viewing.

6.Support data post-processing function

7.Support external running of javascript scripts

6.Introduction to Home Weather Station cloud platform

1.CS architecture software platform supports direct observation on mobile phones and PC browsers without the need to install additional software.

2.Support multiple accounts and multiple devices to log in

3.Support real-time data display and historical data display dashboard

4.Cloud servers and cloud data storage are stable and reliable, easy to expand, and load balanced.

5.Support SMS alarm and threshold setting

6.Support map display and view device information.

7.Support data curve analysis

8.Support data export table format

9.Support data forwarding, HJ-212 protocol, TCP forwarding, http protocol, etc.

10.Support data post-processing function

11.Support external running of javascript scripts
