location：Home>Products>Atmospheric monitoring>Gas Sensors>Oxygen Sensors

Oxygen Sensors

Model：FT-QT5

Brand：fengtu

Oxygen Sensors are used to measure the concentration of oxygen gas in the environment, which can easily and accurately measure the concentration of oxygen in the environment.

Get a Free Quote

Related products

1. Oxygen Sensors Technical Parameters

Oxygen Sensors are used to measure the concentration of oxygen gas in the environment, which can easily and accurately measure the concentration of oxygen in the environment.

model	Measurement parameters	Measuring range	Accuracy	Resolution	unit	Operating temperature	Operating humidity
QT1	Carbon monoxide	0-1000PPM	±2PPM	1PPM	PPM	-20℃-+50℃	10-95%RH non-condensing
QT1S	Carbon monoxide	0-20PPM	≤±5%	0.01PPM	PPM	-20℃-+50℃	10-95%RH non-condensing
QT2	Sulfur dioxide	0-20PPM	±1PPM	0.1PPM	PPM	-20℃-+50℃	10-95%RH non-condensing
QT2S	Sulfur dioxide	0-1PPM	≤±5%	0.001ppm	PPM	-20℃-+50℃	10-95%RH non-condensing
QT3	Nitrogen dioxide	0-20PPM	±1PPM	0.1PPM	PPM	-20℃-+50℃	10-95%RH non-condensing
QT3S	Nitrogen dioxide	0-1PPM	≤±5%	0.001ppm	PPM	-20℃-+50℃	10-95%RH non-condensing
QT4	ozone	0-20PPM	±1PPM	0.1PPM	PPM	-20℃-+50℃	10-95%RH non-condensing
QT4S	ozone	0-1PPM	≤±5%	0.001ppm	PPM	-20℃-+50℃	10-95%RH non-condensing
QT5	Oxygen content	0~30%VOL	±3%FS	0.1%VOL	VOL	-20℃-+50℃	5-95%RH non-condensing
QT6	Negative oxygen ions	0～100,000/cm³	±10%	10pcs/cm³	Pieces/cm³	+10℃-+70℃	10-70%RH without condensation
QT7	Hydrogen sulfide	0-100PPM	±2PPM	1PPM	PPM	-20℃-+50℃	10-95%RH non-condensing
QT8	Methane	0-100%LEL	≤±3%	1%LEL	LEL	-20℃-+50℃	10-95%RH non-condensing
QT9	TVOC	0-100PPM	55±15 nA/ppm	1PPM	PPM	-20℃-+50℃	10-95%RH non-condensing
QT10	Ammonia	0-100PPM	±4PPM	1PPM	PPM	-20℃-+50℃	10-95%RH non-condensing
QT11	Nitric Oxide	0-250PPM	-2~10PPM	1PPM	PPM	-20℃-+50℃	10-95%RH non-condensing
QT12	formaldehyde	0-10PPM	<1PPM	0.1PPM	PPM	-20℃-+50℃	10-95%RH non-condensing
