Anemometer for drones

Product Name: Anemometer for drones

Anemometer for drones is an anemometer designed for use on drones and size, weight and power limiting devices.Anemometer for drones Product Introduction: FT-F1 anemometer is an anemometer that uses the ultrasonic resonance principle.

Specially designed and installed on small aircraft and unmanned platforms to monitor wind speed and direction values in low-altitude areas.

The FT-F1 weighs 56g and has a diameter of 46mm, making it small and light. It is compact and solid, has strong anti-electromagnetic interference, waterproof and dustproof functions, and can work normally at an altitude of 4,000 meters and in an external environment with a temperature between -40°C and +70°C.

It uses a low-power chip inside and can measure wind speeds up to 60m/s. It is especially suitable for unmanned aircraft and their related flight control platforms, as well as environmental monitoring systems using aircraft.

FT-F1 is designed with two installation methods: it can be installed vertically on the top of the aircraft or inverted on the bottom of the aircraft.

Anemometer for drones technical indicators:

Wind speed measurement range 0-60m/s, accuracy 3%, resolution 0.1m/s

Wind direction measurement range 0-359°, accuracy ±3°, resolution 1°

Instrument diameter 46mm

Instrument height 48mm

Instrument weight: 56g

Material:ABS

Color Black

Digital output RS485

Baud rate 4800-19200

Communication protocol ModBus, ASCII

Operating temperature/humidity -40℃-+70℃; 0-100%

Working altitude 0-4000 meters

Power requirement VDC: 5-30V; 15mA (12V)

Installation method: Mount on the top column of the aircraft or hang on the bottom
