Automatic Weather Station

1.Product Introduction of Automatic Weather Station

The Automatic Weather Station detects multiple elements and generates packets for remote transmission to the central station without manual intervention.PQX10Automatic Weather Station is a highly integrated, low-power, quick-to-install, high-precision automatic weather observation equipment that is easy to use for field monitoring.

The equipment supports wireless transmission, requires no debugging, and can be quickly deployed.It is suitable for the acquisition of meteorological data such as short-term emergency meteorological observations and mobile meteorological monitoring.Widely used in meteorology, agriculture and forestry, environmental protection, oceans, airports, ports, scientific expeditions, campus education and other fields.

The device uses a ten-element integrated sensor that can conduct real-time observations of wind speed, wind direction, air temperature, humidity, atmospheric pressure, light, optical rainfall, pm2.5, pm10, noise and other meteorological elements.The sensor shell is made of imported Stainless steel material, which is more Effectively resist salt spray and other environments, with a protection level of IP65 or above.

2.Product features of Automatic Weather Station

1.The ultrasonic probe is hidden in the top cover to avoid interference from rain and snow accumulation and avoid obstruction by natural wind☆

2.The principle is to emit continuous variable frequency ultrasonic signals and detect wind speed and direction by measuring the relative phase☆

3.Integrated sensor with ten elements: temperature, humidity, wind speed, wind direction, atmospheric pressure, optical rainfall, light, pm2.5, pm10, and noise☆

4.Powered by lithium battery, with power display function

5.Shock-absorbing and protective trolley case, easy to carry

6.Aluminum alloy bracket, retractable

7.Android 7-inch touch screen

3.Technical parameters of Automatic Weather Station

1.Wind speed: measurement principle: ultrasonic wave, 0~60m/s (±0.1m/s+0.01V);

2.Wind direction: Measurement principle: ultrasonic, 0~360° (±2°);

3.Air temperature: Measurement principle: diode junction voltage method, -40-80℃ (±0.3℃ (25℃));

4.Air humidity: measurement principle capacitive, 0-100%RH (±3%RH (20%~80%));

5.Atmospheric pressure: measurement principle piezoresistive, 300-1100hpa (±0.25%);

6.PM2.5: Measurement principle: light scattering, 0-1000ug/m³ (±10% (<500 micrograms));

7.PM10: Measurement principle: light scattering, 0-1000ug/m3 (±10% (<500 micrograms));

8.Noise: Measurement principle capacitive, 30-120dB (±1.5dB)

9.Lighting: Measurement principle photoelectric effect, 0-157286LUX (＜±3%)

10.Optical rainfall: measurement principle photoelectric type, 0-4mm/min (≤±4%)

11.Data storage: no less than 500,000 items;

12.Power consumption: 1.75W

13.Lithium battery: capacity 12000maH, battery life ≥32h

14.Total weight of equipment: ≤5kg;

15.Installation time: 1 person, no more than 2 minutes to complete the installation;

16.The production enterprise has ISO quality management system, environmental management system and occupational health management system certification.

17.The production enterprise has a computer software registration certificate

18.The production enterprise is a 3A credit enterprise

4.Introduction to Automatic Weather Station cloud platform

1.CS architecture software platform supports direct observation on mobile phones and PC browsers without installing additional software.

2.Support multiple accounts and multiple devices to log in

3.Support real-time data display and historical data display dashboard

4.Cloud servers and cloud data storage are stable and reliable, easy to expand, and load balanced.

5.Support SMS alarm and threshold setting

6.Support map display and view device information.

7.Support data curve analysis

8.Support data export table format

9.Support data forwarding, HJ-212 protocol, TCP forwarding, http protocol, etc.

10.Support data post-processing function

11.Support external running of javascript scripts
