Portable 10-Parameter Monitoring: The FT-BQX10 Portable Weather Station for Emergency & Scientific Fieldwork

FT-BQX10 Portable Weather Station is a versatile mobile environmental monitoring device developed by Fengtu Technology for short-term temporary meteorological observation needs. It is widely used in various fields such as emergency meteorological observation, field scientific research, and environmental protection monitoring.

01 Highly Integrated and Portable Design

The FT-BQX10 is a highly integrated, low-power, and rapidly deployable high-precision automatic weather observation station. It weighs no more than 5 kg and comes equipped with a shockproof protective trolley case and a retractable aluminum alloy tripod, making it easy to carry and deploy quickly. A single person can complete the setup within two minutes, making it ideal for missions requiring frequent relocation and field monitoring.

02 Monitoring Parameters

The device integrates ten environmental monitoring sensors into a single unit, enabling simultaneous real-time observation of wind speed, wind direction, air temperature, humidity, atmospheric pressure, light intensity, optical rainfall, PM2.5, PM10, and noise. The sensor housing is made of imported ABS material with an IP65 or higher protection rating, providing effective resistance against harsh environments like salt spray. Wind speed and direction are measured using the ultrasonic principle, with probes hidden in the top cover design to avoid interference from rain/snow accumulation and wind obstruction.

03 Data Management and Transmission

The device comes standard with three data transmission methods: GPRS, Bluetooth, and 485-to-USB, and supports data export. The built-in storage capacity can hold no less than 500,000 data records. The supporting software ecosystem includes PC host software, an Android APP, and a Client-Server architecture cloud platform. It supports functions such as real-time data display, historical data query, curve analysis, and threshold alarms. Users can access data directly via computer or mobile browser without requiring additional software installation.

04 Power Supply and Endurance

The device features a built-in removable lithium battery pack with a capacity of 12,000mAh, providing over 50 hours of continuous operation on a full charge, complemented by a power level display function. With an overall power consumption of approximately 1.5W, it ensures reliable performance for extended field operations.
